Advantages of mk Extruded Aluminum Framing & T-Slot Aluminum Extrusions

  1. T Slot Table Extrusion

Heavy Duty Aluminum T-Slot Workbenches Let us design a workbench to meet your application needs. Because we use t-slotted aluminum extrusion, our workbenches are not only durable, but also aesthetically pleasing – and 100% compatible with 80/20, Bosch,. RE15x75 Aluminum Extrusion Table Plate This Mini-Table Plate is just 15x75mm with 2 T slots on one side and 1 T slot on the other side. Ideal for use as a universal mounting platform. Parker’s extensive line of structural T-slot aluminum extrusions, fasteners, panels, doors, hardware and accessories can be configured to meet any design challenge with a durable, high performance solution.

With mk Aluminum Framing and t-slot aluminum extrusions you can build just about anything you can imagine, whether it be machine bases, safety enclosures, perimeter guards, tool racks, robot stands, carts, workstations, display units or something else.

  • Flexibility
  • Fast assembly
  • Easy reconfiguration
  • Cost and labor savings
  • Superior fit and finish
  • Easy-to-use system components
  • Designed for high load applications
  • High strength to weight ratio
  • Corrosion resistance
  • Re-usability of components

All t-slot extruded aluminum systems are engineered for a precise fit and maximum rigidity. Forget the hassles and inflexibility of steel – the welding, grinding, painting and waiting. mk t-slot aluminum extrusions offer you fast assembly, easy reconfiguration and unlimited flexibility.

Machine GuardThis machine guard features yellow paneling with wire mesh access doors and internal docking stations.
Laboratory Work CenterThis custom work center is constructed out of a variety of mk profiles with wood paneling and work-surfaces.
Custom VST ApplicationA custom VST with timing belt driving auxiliary equipment.
Machine GuardThis machine guard features a separate access location for the control panel of the equipment.
T Slot Extrusion Table
Guard with Panel ClipsThis is an example of a a black PVC mesh panel held in place in the t-slot of the extrusion.
Machine GuardThis is an example of a machine guard in a robotic work cell.
Conveyor with Custom GuardThis is an example of a guard constructed with closed-sided profiles, mounted to a conveyor.
Access DoorThis is an access door in a PVC wire mesh guard around a conveyor.
Machine GuardThis is an example of a machine guard used in an OEM application.
Workcell Guardingmk guarding is used to seperate robotic workcells.
Workcell with CartsThis guard features integrated carts, which when in place act as part of the guard, but can be removed as needed.
Guard Corner ExampleThis is an example of a guard with clear polycarbonate paneling.
Custom Plate Linear Module LZRThis is a custom linear module featuring foam filled mk extrusion.
Wire Mesh GuardingPVC coated wire mesh paneling mounted into the t-slot of the guard.
Custom CartThese custom carts are portable and feature different top surfaces.
Conveyor GuardThis conveyor guard feature clear poly-carbonate guarding mounted into the t-slot of the mk extrusion.
Linear Module LZRA mk LZR linear module, with a hollow shaft for motorized operation.
Machine GuardThis machine guard features mk's flat finish profile and clear polycarbonate removable paneling.
Slot
Parallel ConnectorThis is an example of a parallel plate holding sections of guards together.
Machine GuardClear polycarbonate paneling is held in place use mk panel clips. This allows the paneling to be removed.
Glide AssembliesThis is a photo of the three glide assemblies for the 50 system.
Shelving and GuardingThis is an example of a shelf within a wire mesh guard.
Door with Lock and Handlemk offers a wide variety of handles and locks for guarding
Hinge on an Unframed PanelSmall door can be supplied unframed, this hinge would be used.
Types
Machine Guard with Pull OutThis guard features pull out draws for product and process access.
Custom WorkstationThis custom workstation features a ball transfer work surface.
Counter Balance WindowThis is an example of a counter balance window constructed out of mk profile and components.
Storage ContainerThis is a custom storage container with an integrated work surface.
Storage LockersThis is an example of custom designed storage lockers, with blue paneling and flat finish profile construction.
Side Gripper Conveyors with VSTTwo side running conveyors are mounted to a VST linear module which is used to vary the spacing between the conveyor belts.
WorkstationA workstation integrated into a conveyor line.
Work Surfacesmk offers a wide variety of surfaces for workstations.
WorkbenchThis is an example of a height adjustable workbench. The height is adjusted manually using mk's telescoping profile.
T Slot Extrusion Table
Door with LockThis is an example of a door constructed out of mk profile with an integrated key lock.
Pneumatic PortSeveral mk profiles can be pressurized and used as a pneumatic beam. This is an example of an outlet port.
Shop CartsThese shop carts feature red closure strip in the t-slot to make them easily identifiable.
Factory ShelvingThis is an example of storage shelving for a factory.
Laboratory CartThis is an example of a cart designed for use in a laboratory, constructed using mk flat finish profiles.
Motor Driven VSTMotors can be used to drive mk VST linear modules.
VSTTwo examples of mk linear modules, VST
LZR and ConveyorThe LZR is used in combination with other linear modules to move a fixture mounted above the conveyor.
Custom Linear ModuleThis is an example of a custom linear module mounted in a frame constructed out of mk profiles.
WorkstationA workstation complete with an overhead light, power strip, draw, shelf and bins.
Custom CartThis custom cart features shelves on both sides of an open frame.
Vertical VSTThis VST is used to move fixtures vertically.
Linear Module Elevatormk linear module, LZR, is used in an elevator fashion here to move the platform.
Custom Show TableThis piece was designed for use at a trade show for the customer.
Linear ModuleA standard LZR linear module
Aluminum extrusion table plate

Looking for more information on our aluminum framing?

Contact us online or call (860) 769-5500. Our experienced sales staff will be happy to assist you.

  • Metric T Slot Aluminum Profiles
  • Connectors
  • Fasteners
  • Accessories
  • Frame to Floor
  • Panel Accessories
  • CarboSix Carbon Fiber

With T-Slot Aluminum, you get more value than you ever would with welded steel. Need flexibility? You've got it with t-slot aluminum. Need Versatility? Extruded aluminum has that too. Strong in the hot or the cold, corrosion resistant, extruded aluminum has everything you need to get a project done quickly and efficiently. No need to paint or weld unlike steel parts. Get whatever you need built fast and strong with our metric series profiles of extruded aluminum framing.


The T-slot Extruded Aluminum Advantage

For thousands of years humans have been fabricating useful, pleasing furnishings and other structures for the home and workplace out of an impressive range of materials, including straw, mud, stone, wood, brick, iron, steel, and other metals of various sorts. But it is only within the last hundred years or so that aluminum the most abundant metal in the Earth's crust has been utilized in an ever-increasing number of day-to-day applications. Partly this is because a cost-effective process for extracting aluminum from bauxite ore was not perfected until about 1920.

So there is one great advantage of employing aluminum for structural design purposes: it is plentiful. Its other advantageous properties include strength, lightness, formability, high ductility, and excellent corrosion-resistance. The innate utilitarian value of those properties is vastly magnified when the metal is formed into T-slot aluminum extrusions.

In a nutshell, T-slot aluminum forms the basis of a framing system for creating three-dimensional structural assemblies made with a variety of extruded and fabricated aluminum parts. With this system, each length of extruded aluminum contains one or more T-shaped indentations, or slots, into which various attachments (with ends also shaped like a 'T'?) conveniently fit and can slide up and down as needed. This allows you to interconnect other T-slotted aluminum parts into even the most complex configurations without having to clamp and weld them together as you would have to do with steel components.

Here are a few of the key advantages of adopting T-slot aluminum solutions to meet your structural design needs.

Strength

True, steel is harder and 'stronger.' But by the same token, aluminum is among the lightest of metals used for modern engineering purposes, with a molecular density one-third that of steel. As a result, it possesses a strength-to-weight ratio that is actually superior to that of steel . Contrary to what you might think, extruded aluminum is strong enough to handle most structural design and assembly applications.

Once you factor in the inconvenience of moving and positioning heavy pieces of steel not to mention the added labor cost of welding or riveting them together, drilling and tapping holes for mounting bolts, and then cleaning, prepping, priming, and painting the surface of the metal then T-slot aluminum becomes an increasingly attractive option if you are seeking cost-effective structural framing solutions.

Durability

If it's tough enough for trucks, military combat vehicles, and commercial airliners, then rest assured that aluminum is tough enough for more prosaic, everyday purposes. One key aspect of this durability is its resistance to rusting. Rust is to steel as rot is to wood. Unlike steel, for all intents and purposes aluminum doesn't rust at all. A microscopic layer of oxide (which is responsible for the silvery-gray color of anodized aluminum) naturally forms on the surface of the metal and prevents that from happening. You don't even have to prime and paint it in order to protect it! If any of your project's aluminum extrusions or other parts never rust, then you'll never have to replace them saving you money and down-time in the long run.

Versatility

Finally, one of the most important advantages to using T-slot aluminum extrusions and accessories is that, unlike permanently welded steel, the system is modular by design i.e., it is easily changeable. You can connect, position, and fasten together the aluminum profiles however you'd like, using the appropriate fasteners , connectors , and desired accessories . Later on, as needed, you can then adjust and rearrange them in any configuration you like.

The most common type of aluminum fastener used to fasten parts together is the T-nut: just drop it into the T-slot and then twist it into a locked position. That is so much easier than welding!

But where the real magic happens is in the versatility of our aluminum connectors. Just a partial list would include:

  • quick connectors
  • T-connectors
  • tilt connectors
  • milling connectors
  • bolt connectors
  • cube connectors
  • angle connectors
  • slotted gussets
  • corner brackets

Once you've put the finishing touches on the assembly with end caps, casters, cable blocks, machining jigs, tool hangers, cabinet siding, doors, or any of a number of other accessories that we carry, you're good to go!

For maximum versatility for both both our international and domestic customers, be aware that our T-slot aluminum extrusions come in both metric profiles and inch profiles .

From carts to aquarium stands , from shelves to enclosures , and from ergonomic workbenches to eye-catching signs , Framing Tech T-slot aluminum extrusion systems are designed, machined, and assembled for versatility—and they are built to last.


T-Slot Aluminum FAQs

T Slot Table Extrusion

  • What is T-slot Aluminum Extrusion?

    T-slot aluminum extrusion is a structural fabrication material that utilizes an engineered cross-sectional profile that is both strong and versatile in its use.

  • Will T-slot Aluminum Extrusion corrode?

    Our aluminum extrusion is non-corrosive. This is mostly due to the clear anodized finish that comes standard on all of our extrusion, but also due in part to aluminums natural ability to oxidize. The oxidation process creates a secondary layer of protection from corrosion, similar to how copper will patina.

  • Is T-slot Aluminum Extrusion considered a “Green” material?

    Yes! Due to excellent recycling practices most of the aluminum ever produced is still in use today. In fact, aluminum is 100% recyclable and of the most common materials recycled aluminum is the ONLY material that is infinitely recyclable. It is also much lighter than glass and steel per cubic inch, and has a much smaller carbon footprint during fabrication, processing, and shipping.

  • Why choose aluminum extrusion over steel?

    The main advantages are that aluminum extrusion is more versatile, modular, easier to work with, and costs less than steel. Building with aluminum extrusion is as simple as inserting a connector into the t-slot and tightening it into place with standard hand tools. No need to clamp, weld or paint aluminum extrusion. T-slot aluminum extrusion makes it easy to re-locate pieces or add onto your current structure at any time.

    What is aluminum extrusion used for?

    Currently, T-slot aluminum extrusion is widely used in automation, material handling, safety guarding, manufacturing and laboratory applications. However, many people are adopting t-slot aluminum extrusion for use in a wide variety of projects. Some have even built their own machines such as 3D Printers and CNC machines using our aluminum extrusion.

  • What is a T-slot, and how do I use it?

    A T-slot is what we call the channel that runs the length of our aluminum extrusion shapes. The T-slots are designed to a specific depth and width depending on the material. The T-slot is used mostly for mounting and fastening a wide variety of accessories and panels to the aluminum extrusion. Often, panels will be inserted into the T-slot to quickly create a wall or enclosure.
